ARLINGTON, Va., 10 March 2016. U.S. military researchers are moving forward with a project to revolutionize high-end custom IC design for military and aerospace applications.

DARPA and USC researchers moving forward on program to revolutionize high-end custom IC design
DARPA and USC researchers moving forward on program to revolutionize high-end custom IC design
ARLINGTON, Va., 10 March 2016. U.S. military researchers are moving forward with a project to revolutionize high-end custom IC design for military and aerospace applications.

Officials of the U.S. Defense Advanced Research Projects Agency (DARPA) in Arlington, Va., announced $3 million in contract options Wednesday to the USC Information Sciences Institute (ISI) in Los Angeles for the second and third phases of the Circuit Realization at Faster Timescales (CRAFT) – FinFET Foundry/Design Aggregation Services military chips program.

The CRAFT FinFET program seeks to develop a custom IC design flow to reduce the effort to design high-performance custom ICs; help port IC designs to secondary IC foundries and more advanced technologies; and reuse of IC intellectual property.

USC ISI won an $11.8 million sole-source contract last December for the first phase of the CRAFT FinFET program. The options announced this week include an additional $1.2 million for phase 1, $890,524 for phase 2 option 1, and $840,335 for phase 3 option 2. The program's first phase ended last month.

To maintain technology dominance, the U.S. military is developing next-generation systems that require high computational performance in a power-constrained environment. The problem, however, is these technologies cannot be manufactured fast enough. Systems designers today must choose between high performance and low power consumption.

Related: Breakthrough in nitride integrated circuits is aim of $16.2 million DARPA contract to TriQuint Semiconductor

For the most crucial applications, systems designers must choose between a high performing, custom ICs that requires years to design and fabricate, or settle for a 100-times lower-performing general-purpose processor that can be programmed in months.

The DARPA CRAFT program seeks to demonstrate a custom IC design flow and methodology in a leading-edge commercial 16- or 14-nanometer fab, port these designs to new foundry process flows, and increase design reuse by providing a repository for secure storage and distribution of design elements.

The CRAFT has three technical goals: reducing custom IC design and fab cycle time by 10X with new software tools; enabling a 50 percent reuse of critical military IC modules with an intellectual property (IP) repository system; and enabling flexible chip fabrication by porting a technology node from one foundry to another, or migrating from one design node to another design node at the same foundry.

To meet these goals, DARPA needs to build custom ICs using the FinFET leading-edge CMOS process node because of this technology's density, performance, and power advantages. To access this technology, the CRAFT program needs FinFET foundry access, and this is where USC Information Sciences Institute comes in.

Related: DARPA launches WIRED program to develop affordable wafer-scale infrared sensors

USC is providing a design aggregation service for CRAFT contractors as they perform dedicated and foundry-driven FinFET multi-project wafer (MPW) shuttle runs. USC Information Sciences has prior experience in working with leading-edge technologies, and will act as the primary interface between the foundries and DARPA.

USC also will continue collecting individual designs, produce an aggregation of these designs to create the floorplan for the full mask set, and will insert MOSIS designed test structures to provide vital early assessment of the designs, DARPA officials say.

USC is training military and university designers how to use the technology, and maintain and distribute foundry tools and models. USC can provide these services because it can work with classified data and has experience in helping design teams develop and integrate technologies at the FinFET technology node that CRAFT will use.

USC also has an automated infrastructure that provides automated and fast release of process design kits to shuttle run users. For more information contact the USC Information Sciences Institute online at www.isi.edu, or DARPA at www.darpa.mil.
