MIL-STD-1553 mini PCI-Express reference design providing a full size F2 mini PCIe Interface Card supporting one or two dual redundant MIL-STD-1553 channels. PCIe interface uses a small, cost-effective Xilinx Artix-7 FPGA. Kit includes board schematic/layout, FPGA source and software drivers/API. Portable to any board design requiring PCIe. BC, MT and 1 or 2 RTs per channel with 64K Bytes ECC RAM.
