Linear voice coil motor to provide motion control in test and measurement introduced by Moticont

VAN NUYS, Calif. – Moticont in Van Nuys, Calif., is introducing the LVCM-051-127-01 linear voice coil motor for test and measurement, wafer handling, laser machining and drilling, scanning laser beam steering and filtering, and medical applications.

Apr 23rd, 2019
By Mil & Aero staff
By Mil & Aero staff

VAN NUYS, Calif. – Moticont in Van Nuys, Calif., is introducing the LVCM-051-127-01 linear voice coil motor for motion control test and measurement, wafer handling, laser machining and drilling, scanning laser beam steering and filtering, and medical applications.

With a stroke length of 3.75 inches, this 2-inch-diameter linear motor has a high force-to-size ratio of 5 pounds and a peak force of 15.8 pounds at 10-percent duty cycle.

The motor features two 10 to 32 UNC-2B threaded mounting holes in the housing and two 10-32 UNC-2B threaded mounting holes in the coil end for integration into new and existing applications.

This efficient, high force, high acceleration/deceleration, low inertia, clean, zero cogging, brushless motion-control device also is known as a moving coil motor.

Related: Linear voice coil motor for motion control in antenna positioning introduced by Moticont

The motor has a 3.75-inch stroke, and features accuracy and repeatability when operated as a DC servo motor in a closed servo loop. An encoder and servo controller are available.

There are 12 choices in this series of Moticont's LVCM linear motors based on diameter of the motor, and more than 50 models based on length of stroke and force.

For more information contact Moticont online at http://moticont.com.
