Communications on-the-move antenna to link UAVs and military ground vehicles introduced by CPI

CAMARILLO, Calif., 14 May 2015. Communications & Power Industries (CPI) in Camarillo, Calif., is introducing the GMA-100QB communications on-the-move antenna system for communications on-the-move antenna applications on military ground vehicles.

By Mil & Aero staff
By Mil & Aero staff

CAMARILLO, Calif., 14 May 2015. Communications & Power Industries (CPI) in Camarillo, Calif., is introducing the GMA-100QB antenna system for communications on-the-move antenna applications on military ground vehicles.

The GMA-100QB provides on-the-move (OTM) line of sight (LOS) bi-directional communications capability to link military vehicles to unmanned aerial vehicles (UAVs) in L, S, C, and Ku-bands. Capable of Churchville B OTM performance, the GMA-100QB is equipped with high performance motors and drives on both axes to handle high dynamic loads.

The antenna is stabilized by internal AHRS, allowing independence from vehicle data. The receiver with built in received signal strength indicator (RSSI) enables the antenna to scan the sky rapidly for available signals and point to the desired airborne asset, eliminating the delay of external modem decoding of the signal.

Embedded amplifiers on transmit/receive at all bands allow a full communications system with only the addition of external DC power and a modem.

Related: Communications and Power to provide traveling wave tubes for Navy shipboard EW systems

The GMA-100QB includes a compact multiband high gain directional antenna array, enabling long range LOS datalinks, and a broadband omnidirectional antenna for close-in/overhead communications. Frequency band and antenna selection is electronically commanded.

For more information contact the CPI Malibu Division online at www.cpii.com.
