Synchro/resolver input PCI Express board for angular motion control testing introduced by DDC

BOHEMIA, N.Y., 1 July 2016. Data Device Corp. (DDC) in Bohemia, N.Y., is introducing the SB-3625XKX high-accuracy synchro/resolver input PCI Express board for angular motion control testing in production screening and prototype evaluation.

By Mil & Aero staff
By Mil & Aero staff

BOHEMIA, N.Y., 1 July 2016. Data Device Corp. (DDC) in Bohemia, N.Y., is introducing the SB-3625XKX high-accuracy synchro/resolver input PCI Express board for angular motion control testing in production screening and prototype evaluation.

The SB-3625XKX board has a Windows graphical user interface (GUI) and a synchro/resolver LabVIEW support package. It delivers resolution to 1 Arc minute based on DDC's RD-19230 analog-to-digital converter technology, along with a high independent channel density.

The SB-3625XKX input PCI Express card is complemented by DDC's SB-3623XKX Output PCI Express Card, which is in production, with an instrument grade accuracy of 30 arc seconds.

The board offers a convenient method for production and prototype testing of angle measurement systems; a turnkey GUI to operate all board functions; 4 or 8 synchro/resolver input channels, each with independent reference input; accuracy to 1 arc minute; and programmable resolution.

Related: Interface computer introduced by DDC to develop MIL-STD-1553 and ARINC 429 system applications

For more information contact DDC online at www.ddc-web.com.
