Impedance matching pad introduced by BroadWave Technologies to preserve RF and microwave signal integrity

July 17, 2020
Impedance matching pads eliminate impedance mismatches without introducing reflection to the circuit.

GREENWOOD, Ind. – BroadWave Technologies Inc. in Greenwood, Ind., is introducing the model 851-879-FM4 SMA to F impedance matching pad to preserve signal integrity by matching virtually any transmission line.

The model 851-879-FM4 is a 50-Ohm SMA female to 75-Ohm F male impedance matching pad rated at 1-Watt average power.

The operating frequency range is DC to 4 GHz, nominal insertion loss is 5.7 dB and maximum voltage standing wave ration (VSWR) is 1.50:1.

Related: RF detector to convert an RF input signal to a DC output signal introduced by BroadWave Technologies

Impedance matching pads eliminate RF and microwave impedance mismatches without introducing reflection to the circuit.

BroadWave Technologies manufactures more than 160 standard impedance matching pads in different connector combinations, frequency ranges, and impedances.

For more information contact BroadWave Technologies online at
