Broadband RF and microwave power amplifier for communications and EW introduced by NuWaves

MIDDLETOWN, Ohio, 19 Nov. 2015. NuWaves Engineering in Middletown, Ohio, is introducing the NuPower 12B01A upgraded broadband RF and microwave power amplifier for L- and S-band transmitters, data radios, data links, telemetry, and electronic warfare (EW).

Nov 19th, 2015
By Mil & Aero staff
By Mil & Aero staff

MIDDLETOWN, Ohio, 19 Nov. 2015. NuWaves Engineering in Middletown, Ohio, is introducing the NuPower 12B01A upgraded broadband RF and microwave power amplifier for L- and S-band transmitters, data radios, data links, telemetry, and electronic warfare (EW).

The NuPower 12B01A, part number NW-PA-12B01A, replaces the NuPower L- & S-Band Power Amplifier, part number NW-SSPA-10W-1.0-2.5, delivers a minimum of 10 Watts, and typically 13 Watts, of RF power from 1000 to 2500 MHz when sourced with a 0 dBm (1 milliwatt) RF input signal.

Featuring power efficiency in the 30-to-50-percent range, and 40 dB of RF gain, the NuPower 12B01A provides high-efficiency RF amplification for a variety of RF power applications that do not require linear performance.

The power amplifier’s upgraded rugged aluminum chassis 3 by 2 by 0.65 inches and operates in temperatures to 85 degrees Celsius maximum baseplate temperature rating. The unit features a supply voltage range of +11 to +32 volts DC for a variety of applications, including systems running on battery power.

Related: Linear bidirectional amplifier for S-band OFDM radios in unmanned vehicles introduced by NuWaves

An alternative product configuration, part number NW-PA-12B01A-D30, is available with reduced gain that accepts a +30 dBm (1 Watt) RF input signal from the transmitter, supporting a common RF output level of industry data links, such as L-3 Communications’ Bandit. Both standard and alternative product configurations are immediately available for shipment.

For more information contact NuWaves online at www.nuwaves.com.
