Cable assemblies for connecting antennas to mini circuit boards introduced by Fairview

ALLEN, Texas, 11 Nov. 2015. Fairview Microwave Inc. in Allen, Texas, is introducing a family of miniature UMCX, WMCX and HMCX32 cable assemblies for connecting external antennas to mini printed circuit boards.

By Mil & Aero staff
By Mil & Aero staff

ALLEN, Texas, 11 Nov. 2015. Fairview Microwave Inc. in Allen, Texas, is introducing a family of miniature UMCX, WMCX and HMCX32 cable assemblies for connecting external antennas to mini printed circuit boards.

These flexible micro-coax jumpers offer operation from DC to 6 GHz and also are for GPS antennas and other radio systems, Wi-Fi, wireless LAN, Bluetooth, ZigBee, LTE, mini-PCI, and PDA/PCS/cellular handset applications.

Fairview Microwave's UMCX and WMCX cable assemblies have miniature snap-on connectors with mated connection heights ranging from 1.2 to 2.5 millimeters. Fairview is releasing 40 configurations with several coax options including 0.81-, 1.13-, 1.37-millimeter; RG178; and double shielded RG178 (RG178-DS). In-series and between-series cable assemblies are available.

Related: RF and microwave adapters for military and aviation applications introduced by Fairview

The cable assemblies come in standard lengths of 6, 9, and 12 inches, and are RF tested and continuity tested prior to shipment. For more information contact Fairview Microwave online at www.fairviewmicrowave.com.
