Waveguide directional couplers to 33 GHz for radar and SATCOM introduced by Pasternack

IRVINE, Calif., 2 Nov. 2016. Pasternack Enterprises Inc. in Irvine, Calif., is introducing a family of waveguide directional couplers displaying performance to 33 GHz for RF and microwave applications in radar, satellite communications (SATCOM), telecommunications, and wireless transmit-and-receive systems.

By Mil & Aero staff
By Mil & Aero staff

IRVINE, Calif., 2 Nov. 2016. Pasternack Enterprises Inc. in Irvine, Calif., is introducing a family of waveguide directional couplers displaying performance to 33 GHz for RF and microwave applications in radar, satellite communications (SATCOM), telecommunications, and wireless transmit-and-receive systems.

The waveguide directional couplers consists of 74 models spanning a frequency range of 5.85 GHz to 33 GHz across eight frequency bands. The couplers come in two physical configurations including "Crossguide" and "Broadwall" versions and come with either UG-style or CPR-style flanges.

Pasternack's waveguide directional couplers come in waveguide sizes from WR-137 to WR-34 and come in 10, 20, 30, 40 and 50 dB coupling levels with full waveguide operational bandwidth.

These waveguide couplers also boast low insertion loss and typical VSWR of 1.05:1. These couplers are constructed using rugged copper alloy.

For more information contact Pasternack online at www.pasternack.com.
