Sealed D-Subminiature connectors for military, aerospace, and marine uses introduced by TTI

FORT WORTH, Texas, 24 Feb. 2016. Electronics distributor TTI Inc. in Fort Worth, Texas, is offering a range of environmentally sealed D-Subminiature connectors for military, aerospace, and marine applications from TE Connectivity in Harrisburg, Pa.

Feb 24th, 2016
By Mil & Aero staff
By Mil & Aero staff

FORT WORTH, Texas, 24 Feb. 2016. Electronics distributor TTI Inc. in Fort Worth, Texas, is offering a range of environmentally sealed D-Subminiature connectors for military, aerospace, and marine applications from TE Connectivity in Harrisburg, Pa.

The AMPLIMITE D-subminiature range features grommet sealing on the wire-entry and a one-piece interfacial seal on the mating face, as well as internal sealing. They protect against dust and water ingress and exceed IP67 performance levels, having been tested to a depth of 1 meter.

The connectors are available in two series -- series 109 standard-density with size 20 contacts (AWG 24 to 20), and series 90 high density, using size 22 contacts (AWG 28 to 22). The AMPLIMITE cable connectors meet MIL-DTL-24308 and are intermatable with standard D-subminiature interconnects.

Physical specifications include copper alloy contacts plated gold over nickel and cadmium-plated steel shells, with stainless-steel retention clips for added security. Electrical characteristics are current rating 5 amps for the Size 22 contacts and 7.5 amps for the Size 20 contact ranges.

Related: TTI introduces harsh-environment connectors from TE Connectivity for civil aircraft uses

For more information contact TTI online at www.ttii.com.
