Radar-acquisition PCI board to help build radar display systems introduced by Cambridge Pixel

LITLINGTON, England, 29 April 2011. Cambridge Pixel Ltd. in Litlington, England, is introducing the HPx-200 high-performance PCI-based primary radar-acquisition card -- a radar acquisition and processing tool to help build server and client display systems. The HPx-200 interfaces to many kinds of primary radar signals with analog and digital radar video inputs, trigger, and azimuth (ACP/ARP and parallel data) signals. Capturing one or two channels of video at speeds as fast as 50 MHz using 120-bit A/D converters, the HPx-200 uses a field-programmable gate array (FPGA) for pre-processing the radar video before transferring to the client software via the PCI bus.

Pennwell web 420 396
LITLINGTON, England, 29 April 2011. Cambridge Pixel Ltd. in Litlington, England, is introducing the HPx-200 high-performance PCI-based primary radar-acquisition card -- a radar acquisition and processing tool to help build server and client display systems. The HPx-200 interfaces to many kinds of primary radar signals with analog and digital radar video inputs, trigger, and azimuth (ACP/ARP and parallel data) signals.Capturing one or two channels of video at speeds as fast as 50 MHz using 120-bit A/D converters, the HPx-200 uses a field-programmable gate array (FPGA) for pre-processing the radar video before transferring to the client software via the PCI bus.The radar-acquisition card processes differential or discrete radar trigger and azimuth signals, and supports opto-coupled inputs. The HPx-200 has an optional end-of-range signal to terminate sampling.

Software support for the HPx-200 includes Windows and Linux, with a C/C++ board support package. The board is a viable capture solution for systems integrators who run their own processing software, says David Johnson, managing director of Cambridge Pixel.

For more information, contact Cambridge Pixel online at www.cambridgepixel.com.
