Oscilloscopes that users can synchronize to measure 40 channels at once introduced by Agilent
Oscilloscopes that users can synchronize to measure 40 channels at once introduced by Agilent
SANTA CLARA, Calif., 1 April 2014. Agilent Technologies Inc. (NYSE: A) in Santa Clara, Calif., is introducing the Infiniium Z-series oscilloscopes, which can be synchronized for test & measurement of as many as 40 channels simultaneously with a maximum 63-GHz real-time oscilloscope bandwidth on as many as 10 oscilloscopes.

With noise and jitter measurement floors, the oscilloscopes enable engineers to test devices that incorporate new technologies. The Z-series includes 10 models ranging from 20 to 63 GHz, all of which are bandwidth-upgradable to 63 GHz. The Z-series also has fast processing and a next-generation user interface.

Capabilities include bandwidth to capture the third harmonic on 28-, 32-, and 40-gigabit-per-second digital signals; user interface to analyze emerging technologies, including spatial modulation; optional synchronization port to measure as many as 40 channels simultaneously; capacitive touch screen; and USB 3.0 offload speeds.

Related: Debug tool to help DDR memory designers with precompliance testing introduced by Agilent

The Z-series capitalize on key technologies used in the 90000 Q-series oscilloscopes. They include RealEdge technology to enable high-frequency capability while maintaining low noise and jitter.

These oscilloscopes enable engineers to join several Z-series oscilloscopes together; use more than 40 measurement-specific applications, including jitter, triggering. and measurement software, analysis tools, and full-compliance certification test suites; Infiniium offline analysis software, which lets engineers analyze data using oscilloscope software on a PC or laptop; N2807A PrecisionProbe Advanced software to correct for cables to the 63 GHz; and InfiniiMax III probing technology for bandwidths to 30 GHz.

Related: Agilent boosts expertise in high-speed communications test with acquisition of Centellax

Users who bought the 90000 Q-series can upgrade their units to Z-series performance by ordering the N2105A and N2109A upgrade kits. For more information contact Agilent online at www.home.agilent.com.
