Ceramic wirewound chip inductors for high-current power electronics introduced by Coilcraft

CARY, Ill. – Coilcraft Inc. in Cary, Ill., is introducing the 0805HP series ceramic wirewound chip inductors for high-current power electronics applications. The inductors offer high Q factors in an 0805 size at frequencies to 3 GHz.

Aug 3rd, 2017
By Mil & Aero staff
By Mil & Aero staff

CARY, Ill. – Coilcraft Inc. in Cary, Ill., is introducing the 0805HP series ceramic wirewound chip inductors for high-current power electronics applications. The inductors offer high Q factors in an 0805 size at frequencies to 3 GHz.

The 0805HP inductors are available with 23 inductance values ranging from 2.6 to 820 nH, with 2 percent tolerance available for most values.

The 0805HP series features a wirewound construction for high self resonance to 9.5 GHz. It also offers lower DCR (as low as 15 m?) than the previous generation products.

0805HP series inductors feature RoHS compliant, silver-palladium-platinum-glass frit terminations and offer a maximum reflow temperature of 260 degrees Celsius. COTS Plus tin-silver-copper and tin-lead terminations are also available.

For more information contact Coilcraft online at www.coilcraft.com.
