RF and microwave cross guide waveguide couplers for test applications introduced by Pasternack

IRVINE, Calif. – Pasternack Enterprises in Irvine, Calif., is introducing RF and microwave cross guide waveguide couplers with four-, three-, and two-port versions with coax interface that work across C to K bands for instrumentation, test benches, product development, and characterization applications.

Dec 6th, 2017
By Mil & Aero staff
By Mil & Aero staff

IRVINE, Calif. – Pasternack Enterprises in Irvine, Calif., is introducing RF and microwave cross guide waveguide couplers with four-, three-, and two-port versions with coax interface that work across C to K bands for instrumentation, test benches, product development, and characterization applications.

These cross guide couplers consists of 160 parts in three sub-categories: cross guide couplers (four-waveguide ports), cross guide couplers with terminations (three-waveguide ports) and cross guide couplers with terminations and waveguide to coax adapters (two-waveguide ports with either a SMA, type-N or 2.92 mm coaxial connection).

These couplers operate over eight waveguide bands in the 5.85 GHz to 33 GHz frequency range. They are made with bronze waveguide bodies and are offered with EIA (CPR)-style flanges or UG-style flanges per military standard. These cross guide couplers are available with coupling factors from 20 to 50 dB.

For more information contact Pasternack online at www.pasternack.com.
