DARPA looks to Maritime Applied Physics for TERN program to develop long-endurance UAVs for launch from small ships

Aug. 25, 2013
ARLINGTON, Va., 25 Aug. 2013. Researchers at Maritime Applied Physics Corp. (MAPC) in Baltimore will help U.S. military researchers develop a medium-altitude long-endurance unmanned aerial vehicle (UAV) for long-term maritime surveillance that can launch and recover from relatively small ships to provide airborne intelligence, surveillance, and reconnaissance (ISR) and strike mobile targets anywhere, around the clock.

ARLINGTON, Va., 25 Aug. 2013. Researchers at Maritime Applied Physics Corp. (MAPC) in Baltimore will help U.S. military researchers develop a medium-altitude long-endurance unmanned aerial vehicle (UAV) for long-term maritime surveillance that can launch and recover from relatively small ships to provide airborne intelligence, surveillance, and reconnaissance (ISR) and strike mobile targets anywhere, around the clock.

Scientists at the U.S. Defense Advanced Research Projects Agency (DARPA) awarded a $2.2 million contract to MAPC this past week for the initial phase of the Tactically Exploited Reconnaissance Node (TERN) program, which seeks to develop technology to enable small ships to serve as mobile bases for UAVs.

MAPC experts have long experience in developing unmanned vehicles, and helped the Navy prove a concept for an unmanned hydrofoil, company officials say. The company has done research on unmanned surface vessels, personal watercraft, ground vehicles, and sailboats involving sensor fusion, real-time command and control, collision avoidance, and geographic information system (GIS) technologies.

The TERN program, sponsored by the DARPA Tactical Technology Office (TTO) seeks to overcome limitations of Navy shipboard aircraft surveillance. Helicopters are relatively limited in their maximum distances and flight times, for example, while fixed-wing manned and unmanned aircraft must operate from aircraft carriers or large land bases with long runways, although they can fly farther and longer than helicopters.

In the first phase of the TERN program MAPC experts will study designs for an operational TERN UAV, and plan for a prototype flight demonstration in 2017. For the program's initial phase, DARPA officials say they expect to award several contracts totaling as much as $8.9 million, so the contract to MAPC most likely will not be the only TERN first-phase contract.

The TERN program seeks to combine the strengths of aircraft bases on land and sea, by using small ships as mobile launch and recovery sites for medium-altitude long-endurance (MALE) fixed-wing UAVs, DARPA officials say.

The ultimate goal for a TERN UAV and launch system to enable persistent ISR and strike capabilities with payloads of 600 pounds while operating at ranges as long as 900 nautical miles from a host vessel.

The TERN system should be able to operate from several relatively small ship types in rough seas, including the 2,784-ton Independence-class littoral combat ship (LCS), which is 418 feet long and 104 feet wide, with a large aft-located flight deck. Other ships of interest are amphibious transport docks, dock landing ships, and Military Sealift Command cargo ships.

The program will produce a low-cost TERN prototype UAV to demonstrate launch, recovery, and enabling technologies.

DARPA plans to roll out TERN in three phases over three or four years, culminating in a full-scale launch and recovery demonstration. The first phase will include concept definition activities; the second phase will mature technology, with preliminary design; and the last phase will demonstrate a TERN prototype.

A second solicitation will be issued during the first phase of the program to MAPC and other Phase I contractors for TERN Phase II and III work. The second and third phases of the TERN program will be worth about $42 million, DARPA officials say.

From MAPC and other TERN first-phase contractors, DARPA officials are interested in novel launch and recovery techniques; aircraft navigation; ship motion prediction; high lift devices; high stroke recovery or arrestment devices; and compact stowage arrangements. Other technologies of interest include automated maintenance systems; robotic deck handling; automated vehicle preflight checkout.

TERN envisions UAV systems for deep overland ISR and strike missions without forward basing or host nation help. Long radius of action enables access to remote geographic areas while long endurance enables persistent ISR and striking fleeting targets.

A relatively small ship deploying with two or more UAVs could offer high-tempo ISR and strike operations on an as-needed basis, DARPA officials say. The program does not involve helicopters or airships.

Named after the family of sea birds known for flight endurance, TERN aims to make it much easier, quicker and less expensive for the U.S. military to deploy ISR and strike aircraft almost anywhere in the world, DARPA officials say.

The TERN medium-altitude, long-endurance (MALE) UAV and automated launch-and-recovery system will be able to launch a 600-pound payload and fly as far as 600 to 900 nautical miles from its host vessel.

The TERN program envisions a capability "like having a falcon return to the arm of any person equipped to receive it, instead of to the same static perch every time,” says Daniel Patt, the DARPA TERN program manager.

“About 98 percent of the world’s land area lies within 900 nautical miles of ocean coastlines," Patt explains. "Enabling small ships to launch and retrieve long-endurance UAVs on demand would greatly expand our situational awareness and our ability to quickly and flexibly engage in hotspots over land or water.”

For more information contact Maritime Applied Physics Corp. online at www.mapcorp.com, or DARPA online at www.darpa.mil.
