Peregrine rad-hard RFIC regulates power, helps NASA SpaceCube 2.0 deliver impressive on-orbit computing power
SAN DIEGO, 3 Oct. 2013. Officials at Peregrine Semiconductor Corp. (NASDAQ:PSMI), a fabless provider of high-performance radio frequency integrated circuits (RFICs), are receiving early reports from NASA’s Goddard Space Flight Center that the company’s UltraCMOS-based power management solution is delivering uninterrupted high performance while meeting the radiation-hardened (rad-hard) and extreme-temperature requirements at the International Space Station.
Selected for NASA’s SpaceCube 2.0 Hybrid Science Data Processor, Peregrine’s Point-of-Load (POL) DC-DC Buck Regulators with integrated switches helped the design team meet its goals of delivering “order-of-magnitude improvements” in on-orbit computing performance over traditional flight computing systems.
The Goddard Space Flight Center’s SpaceCube systems are “next generation,” on-board science-data processors for space missions. The SpaceCube provides 10 times to 100 times the standard on-board computing power while lowering relative power consumption and cost.
The U.S. Department of Defense (DOD) Space Test Program-Houston 4-ISS SpaceCube Experiment 2.0 (STP-H4-ISE 2.0) marks the maiden voyage of the SpaceCube 2.0 model, which achieved a design goal of reducing the printed circuit board (PCB) card size of the previous model from 8 by 6 inches to 7 by 4 inches, and increasing processing speed.
The extra performance and smaller size enable SpaceCube 2.0 to support four HD cameras and the “FireStation” heliophysics instrumentation package, which detects and measures terrestrial gamma-ray flashes from lightning and thunderstorms.
“We’re building cutting-edge space computing systems at NASA’s Goddard Space Flight Center, so every component within our design must represent the smallest, most efficient, most innovative technology in its class while also meeting harsh radiation- and temperature-durability standards with unfailing reliability,” affirms Dave Petrick, embedded systems group leader at NASA Goddard’s Science Data Processing Branch. “Capable of providing up to 10 amps (10A) of clean power, Peregrine’s space-grade POL power management system was the perfect fit for our system’s needs—literally—offering unmatched 85 to 90 percent power efficiency, configurable load sequencing, as well as a very flexible, monolithic design within the smallest package we found on the market.”
The SpaceCube 2.0 design employs four of Peregrine’s PE99155 point of load (POL) power management chips to provide regulated power at multiple supply voltages for the processing elements, memory and associated circuitry like oscillators and gigabit transceivers.
Peregrine’s small-form-factor design enabled all the regulation functions to be placed on a single PCB, realizing area and overall power-consumption savings over the SpaceCube 1.0 power design, which previously required multiple PCBs using conventional linear-regulator bricks.
Peregrine’s design-configuration tool helped NASA to improve power efficiency by 15 percent, allowing a simplified thermal design and wider operating-temperature range for the system in orbit. In addition, Peregrine’s UltraCMOS technology is immune to latch-up due to cosmic ray strikes (known as single-event latch-ups, or SELs) that are common even in low-earth orbits.
“Peregrine has been supplying components to NASA for more than 12 years,” explains Dave Shepard, vice president of Peregrine’s high-performance solutions business unit. “We are proud to be handling power regulation for NASA’s SpaceCube 2.0 and applaud NASA for its innovative design and the early success reported this week.”
