MIL-STD-1553/1760 dual avionics transceiver for height-restricted uses offered by Holt

MISSION VIEJO, Calif., 27 April 2015. Holt Integrated Circuits in Mission Viejo, Calif., is introducing the HI-2579CG 3.3-volt MIL-STD-1553/1760 dual avionics transceiver for applications using cards with component height restrictions like PMC and XMC.

The HI-2579CG avionics databus interface has integrated dual transformers, and is smaller than 4.6 millimeters when mounted. It is hermetically sealed on a ceramic LCC substrate and dual transformers are mounted in the same package.

The ceramic substrate allows extended-temperature operation from -55 to 125 degrees Celsius and achieves moisture sensitivity level (MSL) 1.

The product is for use specifically with MIL-STD-1553/1760 field-programmable gate array (FPGA) designs, and provides a one-component solution to interface an FPGA with a dual-redundant MIL-STD-1553 bus.

Related: Discrete-to-digital sensor IC for commercial and military avionics introduced by Holt

The devices are available in industrial (-40 to 85 C) and extended (-55 to 125 C) temperature ranges. For more information contact Holt Integrated Circuits online at www.holtic.com.
