HUNTSVILLE, Ala.— Abaco Systems further extended its range of portable avionics devices that feature the Intel Thunderbolt 3 interface with the addition of an ARINC664-compatible RCNIC-A2PA-TB and multiprotocol RAR15XF-TB that supports up to four channels of MIL-STD-1553 and 18 channels of ARINC 429 on a single device. These new devices complement Abaco’s previously announced QPM-1553-TB and RCEI-830A-TB.
Abaco’s Thunderbolt 3 design delivers maximum flexibility and performance to extend the functionality of existing test systems without adding more slots. It also delivers portability and convenience for test and simulation users and for flight-line use. Typical applications include bus analysis/simulation, system integration activities, and flight-line including 615-3 data loading and MRO (Maintenance, Repair and Overhaul).
Thunderbolt 3 throughput is at least 4x faster than the highest speed USB connection, and has orders of magnitude lower latency than USB. It provides customers with a stable roadmap into the future, ensures long-term viability and provides performance advantages over USB-based devices.
Its on-board firmware, large data buffers, and a high-level API are integrated to provide flexibility in monitoring and generating ARINC bus traffic. Simultaneous scheduled and burst mode (FIFO) messaging is supported on all ARINC 429 transmit channels. Each ARINC 429 receive channel provides simultaneous dedicated and buffered mode storage, along with label/SDI filtering.
Previously announced Abaco portable avionics devices featuring the Thunderbolt 3 interface were the RCEI-830A-TB and the QPM-1553-TB.
The RCEI-830A-TB supports up to 16 Tx and 16 Rx ARINC channels with a range of flexible I/O configurations. It provides complete, integrated databus functionality for ARINC 429, ARINC 615-3 dataloader, ARINC 717, ARINC 575 and selected 2-wire, 32-bit protocols. Configurations with ARINC 717 provide support for both ARINC 717 HBP (Harvard Bi-Phase) and BPRZ (Bi-Polar Return to Zero) across a range of bit rate/sub-frame combinations.
The QPM-1553-TB provides high levels of performance, flexibility and interface density for MIL-STD-1553A/B. Standard features include 1 MByte of RAM per channel, real-time bus playback, aperiodic message insertion, error injection/detection, conditional BC branching, 64-bit, 25 nanosecond message timetagging, and "one-shot" BC operation.
