Teledyne e2v’s EV12DS480 digital-to-analog converter approved for space after passing performance tests under ionizing radiation

BREMEN, Germany – Teledyne e2v confirmed during its participation at Space Tech Expo that its EV12DS480 digital-to-analog converter (DAC) has been approved for use in space applications after it experienced irradiation tests. The EV12DS480 is a 12-bit 8 GSps DAC, now ready for space applications, designed for Newspace systems and offered in various reliability grades (including NASA Grade 1). This new DAC provides an analog bandwidth extending beyond 7GHz facilitating multi-band, direct digital synthesis up to K-band (26.5GHz).

The series of tests included Total Ionizing Dose (TID) and Heavy Ions (HI) measurements. The tests were carried out to show that electronic components are capable of performing in a harsh space environment. TID tests were performed to evaluate the functionality and performance parameter drifts of the Device Under Test (DUT). Heavy Ions tests were conducted at the RADiation Effects Facility (RADEF), specialized in applied research around nuclear and accelerator based technologies. The HI tests evaluate the Single Event Latch-up (SEL) and Single Event Effects, which include Single Event Upset (SEU), Single Event Functional Interrupts (SEFI), and Single Event Transient (SET). These tests are important to ensure continuity and minimize drift.

Exposure to heavy ions has allowed Teledyne e2v to draw the following conclusions: no SEL was detected during the irradiation with a LET of 60 MeV.cm²/mg, with no tilt; SETs were observed during the irradiation from 3.6 MeV.cm²/mg to 69.3 MeV.cm²/mg; SEFI were observed during the irradiation from 3.6 MeV.cm²/mg to 69.3 MeV.cm²/mg but all these SEFI were successfully managed by software reconfiguration of the DAC registers.
