Cell phone sensors detect radiation to thwart nuclear terrorism

May 1, 2008
Researchers at Purdue University in West Lafayette, Ind., are working with the state of Indiana to use cell phones to help detect potential terrorist threats such as radiological “dirty bombs” and nuclear weapons.

By John McHale

WEST LAFAYETTE, Ind.—Researchers at Purdue University in West Lafayette, Ind., are working with the state of Indiana to use cell phones to help detect potential terrorist threats such as radiological “dirty bombs” and nuclear weapons.

“The threat from a radiological dirty bomb is significant, especially in metropolitan areas that have dense populations,” says Barry Partridge, director of the Indiana Department of Transportation’s (INDOT’s) Division of Research and Development in Indianapolis.

Such a system could blanket the nation with a network of millions of cell phones equipped with radiation sensors able to detect even light residues of radioactive material.

Researchers at Purdue University and officials from the Indiana Department of Transportation are developing a sensor network of cell phones to detect radiation threats. Because cell phones already contain global positioning locators, the network of phones would serve as a tracking system.
Click here to enlarge image

Because cell phones already contain global positioning locators, the network of phones would serve as a tracking system, says Purdue physics professor Ephraim Fischbach. Fischbach is working with Jere Jenkins, director of Purdue’s radiation laboratories within the School of Nuclear Engineering on the project.

“It’s the ubiquitous nature of cell phones and other portable electronic devices that give this system its power,” Fischbach says. “It’s meant to be small, cheap, and eventually built into laptops, personal digital assistants, and cell phones.”

Andrew Longman, a consulting instrumentation scientist, developed the software and then worked with Purdue researchers to integrate the software with radiation detectors and cell phones. Cellular data air time was provided by AT&T.

INDOT paid for the research through the Joint Transportation Research Program and School of Civil Engineering at Purdue.

“The likely targets of a potential terrorist attack would be big cities with concentrated populations, and a system like this would make it difficult for someone to go undetected with a radiological dirty bomb in such an area,” Longman says. “The more people are walking around with cell phones and PDAs, the easier it would be to detect and catch the perpetrator. We are asking the public to push for this.”

Tiny solid-state radiation sensors are commercially available, Purdue researchers say. The detection system would require additional circuitry and would not add significant bulk to portable electronic products, Fischbach says.

“Cell phones today also function as Internet computers that can report their locations and data to towers in real time,” Fischbach explains. “So this system would use the same process to send an extra signal to a home station. The software can uncover information from this data and evaluate the levels of radiation.”

The researchers tested the system in November, demonstrating that it can detect a weak radiation source from 15 feet away.

“We set up a test source on campus, and people randomly walked around carrying these detectors,” Jenkins says. “The test was extremely safe because we used a weak, sealed radiation source, and we went through all the necessary approval processes required for radiological safety. This was a source much weaker than you would see with a radiological dirty bomb.” Officials from INDOT participated in the test.

Long before the sensors would detect significant radiation, the system would send data to a receiving center.

“The sensors don’t really perform the detection task individually,” Fischbach says. “The collective action of the sensors, combined with the software analysis, detects the source. The system would transmit signals to a data center, and the data center would transmit information to authorities without alerting the person carrying the phone. Say a car is transporting radioactive material for a bomb, and that car is driving down Meridian Street in Indianapolis or Fifth Avenue in New York. As the car passes people, their cell phones individually would send signals to a command center, allowing authorities to track the source.”

The signal grows weaker with increasing distance from the source, and the software is able to use the data from many cell phones to pinpoint the location of the radiation source.

“So the system would know that you were getting closer or farther from something hot,” Jenkins adds. “If I had handled radioactive material and you were sitting near me at a restaurant, this system would be sensitive enough to detect the residue.”

In addition to detecting radiological dirty bombs designed to scatter hazardous radioactive materials over an area, the system also could be used to detect nuclear weapons, which create a nuclear chain reaction that causes a powerful explosion. The system also could be used to detect spills of radioactive materials.

“It’s impossible to completely shield a weapon’s radioactive material without making the device too heavy to transport,” Jenkins says.

The system could be trained to ignore known radiation sources, such as hospitals, and radiation from certain common items, such as bananas, which contain a radioactive isotope of potassium.

“The radiological dirty bomb or a suitcase nuclear weapon is going to give off higher levels of radiation than those background sources,” Fischbach says. “The system would be sensitive enough to detect these tiny levels of radiation, but it would be smart enough to discern which sources posed potential threats and which are harmless.”

The team is working with Karen White, senior technology manager at the Purdue Research Foundation, to commercialize the system. The foundation owns patents associated with the technology licensed through the Office of Technology Commercialization.

For more information on licensing the cell phone sensor technology, contact White at 765-494-2609, [email protected].
