Miniature triaxial accelerometers for electronics and engine testing introduced by Meggitt

Oct. 31, 2012
SAN JUAN CAPISTRANO, Calif., 31 Oct. 2012. Meggitt Sensing Systems in San Juan Capistrano, Calif., is introducing the Endevco 35A miniature triaxial ISOTRON piezoelectric accelerometer for high-precision shock and vibration testing of hard drives, electronic peripherals, engine rotor and stator blades, and other electronic components and equipment.

SAN JUAN CAPISTRANO, Calif., 31 Oct. 2012. Meggitt Sensing Systems in San Juan Capistrano, Calif., is introducing the Endevco 35A miniature triaxial ISOTRON piezoelectric accelerometer for high-precision shock and vibration test & measurement of hard drives, electronic peripherals, engine rotor and stator blades, and other electronic components and equipment.

The shear mode Endevco 35A provides a measurement package for the collection of IEPE acceleration data across three orthogonal axes. The integral internal amplifier of the model 35A converts high-impedance accelerometer charge input into low-impedance voltage output. Output is transmitted through the same wires that supply required 4 milliamps constant current power.

Signal ground is connected to the outer case. The unit is delivered with pre-installed fine gauge (34 AWG) wires as output leads, all of which are field repairable. A lead assembly may further be factory reinstalled.

Also included is the four-conductor Endevco 3027AM5-120 cable terminating in three BNC connectors. The cable is shipped as an accessory for installation by the customer. A tool is also provided for easy field installation and removal. Units weigh just 1.1 grams without cable and are adhesive mounted for minimized mass loading.

For more information contact Meggitt Sensing Systems online at www.meggittsensingsystems.com.
