IRVINE, Calif., 14 Feb. 2013. Geotest-Marvin Test Systems Inc. in Irvine, Calif., is introducing the GX6196 6U PXI switch and control board that can be used to create custom switching, signal conditioning, or custom control interfaces for test and measurement applications.
Switching and control resources are available via five inter-board connectors which interface to the user defined mezzanine board, which provides all connections to the unit under test via two 78 pin D-sub connectors.
By providing access and control to all 96 relays, users have the option to create custom relay configurations, custom switched load board configurations. or even custom interface circuitry controlled by the module’s software function calls.
The GX6196 comes with a software package which includes a virtual instrument panel and Windows 32/64-bit driver libraries for ATEasy, LabView, LabView/Real-Time, C/C++, Microsoft Visual Basic, Linux 32/64, Delphi, and Pascal.
For more information contact Geotest-Marvin Test Systems online at www.geotestinc.com.
