SUNNYVALE, Calif. – KRYTAR Inc. in Sunnyvale, Calif., is introducing the model 110050030 dual-directional RF and microwave coupler for electronic warfare (EW), 5G communications, satellite communications (SATCOM), radar, and antenna beam forming.
The model 110050030 offers 30 dB of coupling over the broadband frequency range of 10 to 50 GHz (X through Q-Bands), in a compact and lightweight package.
The RF and microwave coupler is for systems applications that require external leveling, precise monitoring, signal mixing, or swept transmission and reflection measurements.
The directional coupler also lends itself to wireless designs and many test and measurement applications from X through Q-band including commercial wireless, signal monitoring and measurement, and EMC testing.
Related: Mil-spec RF and microwave directional coupler for electronic warfare introduced by KRYTAR
The model 110050030 offers nominal coupling of 30 decibels, plus-or-minus 2.0 decibels, and frequency sensitivity of plus-or-minus 2.0 decibels. The directional coupler exhibits insertion loss of less than 1.5 decibels, directivity of greater than 10 decibels, maximum voltage standing wave ratio (VSWR) is 1.9, input power rating is 20 Watts average, and 3 kilowatts peak.
The coupler comes with industry-standard 2.4-millimeter SMA female connectors. The package measures 1.12 by 0.40 by 0.62 inches, and weighs one ounce. Operating temperature is -54 to 85 degrees Celsius. The directional coupler also can be manufactured to military specifications.
For more information contact Krytar online at https://krytar.com.
