Elbit to provide Navy with helmet-mounted displays for MH-60S helicopter crews with on-visor symbology

June 26, 2020
Display system helps MH-60 pilots to point sensors and weapons via symbology, and designate fixed points on the ground via look-and-click capability.

CRANE, Ind. – Electro-optics experts at Elbit Systems of America in Fort Worth, Texas, will provide the U.S. Navy with helmet-mounted displays for pilots of MH-60S multimission helicopters under terms of a $32 million contract announced Wednesday.

Officials of the U.S. Naval Surface Warfare Center Crane Division in Crane, Ind., are asking Elbit to provide 76 helmet display tracker systems (HDTS) for MH-60S helicopter pilots.

The HDTS provides MH-60 situational awareness and targeting enhancements via pilot/copilot line-of-sight capability; continuously computed impact point for the 20-millimeter automatic gun helicopter armament subsystem; LAU-61C/A 2.75-inch unguided rockets; and LAU-61G/A precision guided digital rocket launcher.

The MH-60S helicopter is for search-and-rescue, MEDEVAC, utility, and vertical replenishment that can operate from aircraft carriers and from other surface warships equipped with helipads. The HDTS also is compatible with the Navy's MH-60R anti-submarine warfare (ASW) and anti-surface warfare helicopter.

Related: Collins to provide night-vision helmet-mounted display for air crews flying in degraded visual conditions

The magnetic HDTS helps reduce the MH-60 helicopter pilot's workload and improve crew coordination. The HDTS represents a relatively simple upgrade to the predecessor HUD on the MH-60 rotorcraft.

The MH-60's HDTS provides electronic symbology on the pilot's visor to enable the helicopter's pilots work together. The system is designed to eliminate confusion in the cockpit; drive weapon systems and control the helicopter's electro-optical sensors, and offer hands-free operation.

The Elbit HDTS can slave or slew weapons and sensors with the “big picture” rather than the “soda straw” view of a multifunction display, Elbit officials say.

Related: Elbit to provide spare circuit cards for Apache helicopter helmet-mounted targeting system

The system enables MH-60 pilots to know always where sensors and weapons are looking via symbology, designates fixed points on the ground via look-and-click capability, and uses components that the military already has in stock for other helicopters and fixed-wing aircraft such as CH-47 Chinook helicopter, UH-60 Black Hawk helicopter, V-22 Osprey tiltrotor, F-22 Raptor jet fighter, and F/A-18 Hornet strike fighter.

The HDTS capability to boresight the system in the aircraft offers increased convenience for pilots over the legacy system, and eliminates the obsolete rail linkage system to improve head mobility and increase aircrew safety. The HDTS symbol set also increased heads-up capability to improve situational awareness.

On this order Elbit will do the work in Haifa, Israel; and Fort Worth, Texas, and should be finished by June 2021. For more information contact Elbit systems of America online at www.elbitsystems-us.com, or the Naval Surface Warfare Center-Crane at www.navsea.navy.mil/Home/Warfare-Centers/NSWC-Crane.
