Navy asks Lockheed Martin to build additional Trident II D5 submarine-launched ballistic nuclear missiles

Oct. 7, 2020
The Trident II D5 is the primary U.S. sea-based nuclear ballistic missile, and is deployed aboard U.S. Navy Ohio-class ballistic missile submarines.

WASHINGTON – Strategic weapons experts at Lockheed Martin Corp. will build additional UGM-133A Trident II D5 submarine-launched ballistic nuclear missiles and support deployed D5 nuclear weapons under terms of a half-billion-dollar order announced last week.

Officials of the U.S. Navy Strategic Systems Programs (SSP) office in Washington are awarding a $498.4 million contract modification to the Lockheed Martin Space Systems segment in Titusville, Fla., to provide for Trident II (D5) missile production and deployed systems support.

The Trident II D5 is one of the most advanced long-range submarine-launched nuclear missiles in the world. It is the primary U.S. sea-based nuclear ballistic missile, and is deployed aboard U.S. Navy Ohio-class ballistic missile submarines.

The U.S. Navy operates 14 of these ballistic missile submarines, each of which can carry as many as 24 Trident II missiles. Although the Trident II is designed to carry as many as 12 multiple independently targetable reentry vehicle (MIRV) warheads, current treaties reduce this number to four or five.

Related: Navy asks Lockheed Martin to build additional Trident II D5 submarine-launched nuclear missiles

Each Trident II missile has a range of 4,000 to 7,000 miles. The Trident II D5 was first deployed in 1990 and is scheduled to remain in service until at least 2027.

The Navy started the D5 Life Extension Program in 2002 to replace obsolete components using as many commercial off-the-shelf (COTS) parts as possible to keep costs down and to enhance the missile's capability. Draper Lab is in charge of upgrading the Trident II's guidance system, and has been working on this project since 2005.

In practice, the Trident II missile's inertial measurement system receives targeting data from computers aboard the submarine. The inertial measurement unit then transmits signals to the D5 flight-control computer and converts them into steering commands to keep the ballistic missile on target.

The missile's post-boost control system maneuvers the missile in flight to observe stars for the missile's celestial navigation subsystem, which updates the inertial system in flight.

Related: Draper Lab to provide additional guidance systems for Trident submarine-launched ballistic nuclear missiles

Lockheed Martin also is integrating the Trident II onto the next-generation ballistic submarine designs of the U.S. and United Kingdom by adapting the Trident II missile and reentry subsystems into the common missile compartment for the future Columbia-class missile submarine and United Kingdom Dreadnought class missile boats.

The Columbia-class ballistic missile submarine is being designed to replace the Navy's fleet of Ohio-class submarines. The future United Kingdom Dreadnought submarine, meanwhile, will replace the Royal Navy's fleet of Vanguard-class ballistic missile submarines.

The U.S. Navy today operates 18 Ohio-class submarines -- 14 of which carry the Trident nuclear missile. Four Ohio-class subs have been modified to carry conventionally armed long-range cruise missiles.

Related: Draper Lab to help enhance accuracy and power of Navy's submarine-launched nuclear missiles

The Ohio-class submarine has been in commission since 1981, and this class is scheduled to be decommissioned and replaced starting in 2029. The United Kingdom Vanguard-class ballistic missile submarine has been at sea since 1993. The Royal Navy operates four Vanguard-class subs.

On this order Lockheed Martin will do the work in Cape Canaveral and Titusville, Fla.; Kings Bay, Ga.; Bangor, Wash.; Sunnyvale, Calif.; Denver; Magna, Utah; Bethesda, Md.; and other U.S. locations, and should be finished by September 2026.

For more information contact Lockheed Martin Space Systems online at www.lockheedmartin.com, or the Navy Strategic Systems Programs office at www.ssp.navy.mil.
