Lockheed Martin to build three MH-60R anti-submarine warfare (ASW) helicopters and avionics for U.S. Navy

July 1, 2021
The multimission MH-60R helicopter has sophisticated sensors and avionics, and operates from frigates, destroyers, cruisers, and aircraft carriers.

PATUXENT RIVER NAS, Md. – U.S. Navy anti-submarine warfare (ASW) experts are asking Lockheed Martin Corp. to build three MH-60R ASW helicopters as replacement-in-kind for the Navy under terms of a $129 million order announced Tuesday.

Officials of the Naval Air Systems Command at Patuxent River Naval Air Station are asking the Lockheed Martin Rotary and Mission Systems segment in Owego, N.Y., to build the new MH-60R helicopters, one of the latest versions of the Sikorsky Seahawk, which is based on the U.S. Army Sikorsky UH-60 Black Hawk utility helicopter.

The multimission MH-60R helicopters have sophisticated sensors, and are designed for anti-submarine and anti-surface warfare. The MH-60R is designed to operate from frigates, destroyers, cruisers, and aircraft carriers. The helicopter has a hinged tail to reduce its necessary storage area aboard ships.

The MH-60R cockpit also has secure VHF/UHF communication; inertial navigation system; satellite communications; data link; and accommodation for forward-looking infrared sensors and night-vision goggles.

Related: Navy asks Northrop Grumman to build 228 avionics mission computers for AH-1Z Viper and UH-1Y helicopters

In addition to its anti-submarine and anti-ship capabilities, the helicopter can handle naval special warfare insertion; search and rescue; combat search and rescue; vertical replenishment; and medical evacuation missions. The aircraft has a rescue hoist for search and rescue.

The Navy MH-60R helicopters have avionics that include the common datalink AN/SRQ-4 Hawklink shipboard terminal system from the L3Harris Communication Systems-West in Salt Lake City.

The AN/SRQ-4 Hawklink shipboard terminal enables surface ships like the Arleigh Burke-class destroyer and the MH-60R helicopter to share information from radar, video, network, and acoustic data interfaces, and enables naval personnel to use aircraft sensor data in real time to extend situational awareness over the horizon. It has a range of about 100 nautical miles.

Related: Honeywell to provide GPS/INS navigation avionics for Army and Navy helicopters, aircraft carrier landing systems

MH-60R pilots use helmet display tracker systems (HDTS) from Elbit Systems of America in Fort Worth, Texas, which provides situational awareness and targeting enhancements via pilot/copilot line-of-sight capability; continuously computed impact point for the 20-millimeter automatic gun helicopter armament subsystem; LAU-61C/A 2.75-inch unguided rockets; and LAU-61G/A precision guided digital rocket launcher.

The helicopter also has the AN/APS-153(V)1 automatic radar periscope detection and discrimination multi-mode radar from Telephonics Corp. in Farmingdale, N.Y., which is designed to detect and classify submarine periscopes as they pop briefly out of the water.

The APS-153 radar is rugged, lightweight, has low-prime power, offers extremely small target detection, high-resolution imaging, and long-range surface search.

Related: Sikorsky makes preparations to build nine new CH-53K heavy-lift helicopters and avionics for U.S. Marines

The MH-60R helicopter can fly as fast as 144 knots at altitudes to nearly 15,000 feet. Its avionics include Enhanced Advanced Flight Control System (AFCS) with naval modules and coupled hover capability, as well as four our 8-by-10-inch color multifunction mission displays that are sunlight readable and night vision device capable.

The MH-60R uses many sensors, including the ASE package, MTS-FLIR, the AN/APS-147 multi-mode radar/IFF interrogator, an advanced airborne fleet data link, and an airborne active sonar. The helicopter includes instrumentation based on the MH-60S glass cockpit, and uses digital monitors instead of an array of gauges and dials. The aircraft can be armed with Mk-54 torpedoes and Hellfire missiles.

On this order Lockheed Martin will do the work in Owego, N.Y; Stratford, Conn.; and Troy, Ala., and should be finished by May 2025. For more information contact Lockheed Martin Rotary and Mission Systems online at www.lockheedmartin.com, or Naval Air Systems Command at www.navair.navy.mil.
