Lockheed Martin picks BAE Systems for RF and microwave missile seekers and sensors for LRASM targeting

June 15, 2022
The LRASM seeker has long-range sensors and targeting that help the stealthy missile find and engage protected enemy ships amid jamming and spoofing.

NASHUA, N.H. – Munitions guidance experts at the BAE Systems Electronic Systems segment in Nashua, N.H., will provide next-generation missile seekers for the Long Range Anti-Ship Missile (LRASM) under terms of a $38 million contract from Lockheed Martin Corp.

The BAE Systems advanced RF and microwave sensor enables LRASM to strike high-value maritime targets from long range in aggressive electronic warfare (EW) jamming environments.

The seeker comprises long-range sensors and targeting technology that help the stealthy missile find and engage protected enemy ships amid attempts to jam or spoof the missile, BAE Systems officials say.

LRASM is for use against high-priority enemy targets like aircraft carriers, troop transport ships, and guided-missile cruisers. The LRASM anti-ship missile contract will support missiles for the U.S. Navy, Air Force, and U.S. allies.

Related: BAE Systems to provide sensor fusion-based missile seekers for Lockheed Martin LRASM in $60 million contract

The BAE Systems LRASM seeker uses sensor fusion to blend information from the missile's on-board radar, semi-autonomous guidance, Global Positioning System (GPS) satellite navigation, high-speed secure tactical networking links, and nearby sensors to strike high-value targets from long range while avoiding shipboard missile counter-fire.

The missile guidance sensor uses semi-autonomous guidance and target cueing data to locate and attack targets precisely and reduce reliance on airborne intelligence, surveillance, and reconnaissance (ISR) aircraft, networking links, and GPS navigation.

BAE Systems designers also are working to make the seeker system smaller, more capable, and more efficient to produce. Building LRASM is the Lockheed Martin Missiles and Fire Control segment in Orlando, Fla. Lockheed Martin is in charge of LRASM overall development, and the BAE Systems is developing the LRASM onboard sensor systems.

LRASM is a joint project of the U.S. Defense Advanced Projects Agency (DARPA) in Arlington, Va., the Navy, and the Air Force to design an advanced anti-ship missile that can launch from B-1B Lancer jet bombers, F/A-18E/F Super Hornet jet fighter-bombers, F-35 Lightning II strike fighters, P-8A Poseidon maritime patrol aircraft, and surface vessels via the Mark 41 Vertical Launching System (VLS).

Related: Lockheed Martin to build radar- and infrared-guided missile defense interceptors in $304.9 million deal

The missile travels at high subsonic speeds, and likely will give way in the future to expected new generations of hypersonic missiles. Submarine-launched versions are under consideration.

LRASM is designed to detect and destroy high-priority targets within groups of ships from extended ranges in electronic warfare jamming environments. It is a precision-guided, anti-ship standoff missile based on the Lockheed Martin Joint Air-to-Surface Standoff Missile-Extended Range (JASSM-ER).

The advanced anti-ship missile is intended to replace the ageing Harpoon anti-ship missile. It has a multi-mode radio frequency sensor, a new weapon data-link and altimeter, and an uprated power system.

The LRASM can be guided toward enemy ships from as far away as 200 nautical miles by its launch aircraft, can receive updates via its datalink, or can use onboard sensors to find its target. LRASM will fly towards its target at medium altitude then drop to low altitude for a sea skimming approach to counter shipboard anti-missile defenses.

Related: Raytheon to stave-off component obsolescence in StormBreaker multimode seeker-equipped air-to-ground missiles

The LRASM uses on-board targeting systems to acquire the target independently without the presence of intelligence or supporting services like GPS satellite navigation and data links. Lockheed Martin is designing he missile with advanced counter-countermeasures to evade hostile active defense systems.

The Lockheed Martin LRASM has a 1,000-pound penetrator and blast-fragmentation warhead, multi-mode sensor, weapon data link, and enhanced digital anti-jam global positioning system to detect and destroy selected surface targets within groups of ships.

LRASM development is in response to a gap in Navy anti-ship missile technology identified in 2008. The standard Navy anti-ship missile is the subsonic Harpoon, which has been in the inventory since 1977.

On this contract BAE Systems will do the work in Wayne, N.J.; Greenlawn, N.Y.; and Nashua, N.H. For more information contact BAE Systems online at www.baesystems.com, or Lockheed Martin Missiles and Fire Control at www.lockheedmartin.com.
