2.2-5 form factor RF connector for applications with critical signal capacities introduced by Molex

LISLE, Ill. – Molex Inc. in Lisle, Ill., is introducing the compact 2.2-5 RF connector system and cable assemblies for high-frequency and low passive intermodulation (PIM).

Mar 25th, 2019
By Mil & Aero staff
By Mil & Aero staff

LISLE, Ill. – Molex Inc. in Lisle, Ill., is introducing the compact 2.2-5 RF connector system and cable assemblies for high-frequency and low passive intermodulation (PIM).

Molex developed the 2.25 form factor together with the 2.2-5 consortium by adapting and miniaturizing the 4.3-10 form factor. Molex 2.2-5 RF connectors are 53 percent smaller than 4.3-10 connectors, and capable of frequencies to 6 GHz.

Wireless and 5G network infrastructures require coaxial jumpers that can deliver premium electrical performance and robust environmental capabilities to withstand the elements. Molex 2.2-5 RF cable jumpers are factory fabricated and provide a IP68 NEMA rating when mated, protecting the connector system from dust and water ingress.

Related: Rugged coax cable for radar, military vehicles, missiles, and space introduced by Molex

Molex offers custom assemblies integrating 2.2-5 form factor connectors in a range of mating options for design flexibility, ease of installation, and optimal electrical performance.

The IP68 2.2-5 system features an air dielectric interface enabling superior bandwidth and low insertion loss in 5G networks and any application with critical signal capacities and space.

For more information contact Molex online at www.molex.com.
