Network analyzer and spectrum analyzer for testing circuit designs for 5G communications offered by SIGLENT
SOLON, Ohio – SIGLENT Technologies America Inc. in Solon, Ohio, is introducing the model SVA1075X spectrum and vector network analyzer and the model SSA3075X spectrum analyzer for testing circuit designs for 5G communications applications.
The model SVA1075X is a spectrum and vector network analyzer has a frequency range to 7.5 GHz, and the model SSA3075X spectrum analyzer offers frequency ranges to 7.5 GHz.
Both test instruments offer 10.1-inch touch screen, web server for remote control, the ability to connect external mouse and keyboard, and an intuitive menu structure.
Options include additional broadcast measurement functions such as Channel Power, Occupied Bandwidth, Carrier-to-Noise Ratio, Harmonics, Third Order Intercept, and Spectrogram bundled in one SVA1000X-AMK option.
The optional SVA1000X-AMA/DMA vector signal analysis offers detailed modulation analysis to enable test and measurement users to visualize signal distortion and interference within a constellation diagram.
For electromagnetic pre-compliance testing, these instruments also feature an EMI filter (200 Hz, 9 kHz, 120 kHz and 1 MHz) and quasi-peak detector package that can be retrofitted with software to simplify EMC pre-compliance measurements.
To address the needs of antenna installations, the SVA1000X series can be upgraded with a distance-to-fault measurement function, which enables the user to detect defects on cables or improper connections.
For more information contact SIGLENT Technologies online at https://siglentna.com.
