VITA 57.4 loopback card products for FPGA transceiver design and test introduced by Samtec

NEW ALBANY, Ind. – Samtec in New Albany, Ind., is introducing the VITA 57.4 FMC+ HSPC loopback card and the VITA 57.4 FMC+ HSPC/HSPCe loopback card to provide field-programmable gate array (FPGA) embedded computing designers easy to use loopback options for testing low-speed and high-speed multi-gigabit transceivers on any FPGA development board or FPGA carrier card.

Jan 18th, 2018
By Mil & Aero staff
By Mil & Aero staff

NEW ALBANY, Ind. – Samtec in New Albany, Ind., is introducing the VITA 57.4 FMC+ HSPC loopback card and the VITA 57.4 FMC+ HSPC/HSPCe loopback card to provide field-programmable gate array (FPGA) embedded computing designers easy to use loopback options for testing low-speed and high-speed multi-gigabit transceivers on any FPGA development board or FPGA carrier card.

The two VITA 57.4-compliant FMC+ loopback cards each come in VITA 57.4-compliant form factors, and feature optimized SI performance via Samtec Final Inch break-our region (BOR) PCB trace routing for the VITA 57.4 FMC+ connectors included in the cards.

The VITA 57.4 FMC+ HSPC loopback card includes one HSPC VITA 57.4 FMC+ connector (Samtec P/N ASP-184330-01). It supports 24 high-speed multi-gigabit transceivers operating at data rates to 28 gigabits per second per channel.

The VITA 57.4 FMC+ HSPC/HSPCe loopback card includes one HSPC VITA 57.4 FMC+ connector (Samtec P/N ASP-184330-01) and HSPCe VITA 57.4 FMC+ connector (Samtec P/N ASP-186900-01). It supports as many as 32 high-speed multi-gigabit transceivers operating at data rates to 28 gigabits per second per channel.

For more information contact Samtec online at www.samtec.com.
