One Component, Dual Cure Epoxy for Medical Applications

June 25, 2024

Master Bond UV15DC80-1Med offers a unique dual cure mechanism utilizing UV light for initial fixation followed by heat for complete polymerization. This addresses limitations of traditional UV adhesives by effectively curing shadowed areas that wouldn't receive sufficient UV exposure, making it suitable for intricate parts and complex geometries. Notably, the adhesive meets ISO 10993-5 cytotoxicity standards, demonstrating biocompatibility for medical device applications.

UV15DC80-1Med has excellent resistance to radiation, liquid sterilants and autoclaving. This one part, no-mix epoxy has a moderate viscosity of 20,000-40,000 cps for versatile dispensing. It delivers strong bonds to various substrates, including metals, glass, ceramics, and many plastics, with a tensile strength exceeding 5,000 psi at 75°F. The cured adhesive offers a wide service temperature range from -80°F to +350°F (-62°C to +177°C) and a high glass transition temperature of 125-135°C. Additionally, it maintains optical clarity with a refractive index of 1.52 at 589 nm.

As a cationic system, UV15DC80-1Med exhibits minimal sensitivity to oxygen. The initial UV cure/tack can be achieved in seconds with UV light (325-365 nm) at a minimum UV radiation intensity of 20-40 mW/cm2. Areas with limited UV access need to be subsequently cured with heat at 80°C within 40-60 minutes. To maximize performance, post-cure at 80°C for 2-4 hours or 125°C for 30-60 minutes is recommended. UV15DC80-1Med is available in various container sizes, ranging from a ½ pint to 5 gallons, to suit project needs. It's also offered in convenient 30 cc syringes for manual or automated dispensing.

Master Bond Adhesives for Medical Device Manufacturing

Master Bond offers adhesives, sealants, coatings and potting/encapsulation compounds that pass one or both standard tests used to determine their suitability for medical device applications: U.S. Pharmacopeia (USP) Class VI for biocompatibility and/or ISO 10993-5 for non-cytotoxicity. These compounds include epoxies, silicones, UV/LED light, or dual curing systems and other chemistries. Read more about Master Bond’s biocompatible adhesive systems for medical devices at or contact Tech Support. Phone: +1-201-343-8983 Fax: +1-201-343-2132 Email: [email protected].
