TDK EPCOS EMC power electronics filters for power supplies available in Europe from TTI Inc.

FORT WORTH, Texas, 22 March 2016. TDK’s range of EPCOS EMC power electronics filters is available in Europe at the TTI Inc. distributor of electronic components based on Fort Worth, Texas.

Mar 22nd, 2016
By Mil & Aero staff
By Mil & Aero staff

FORT WORTH, Texas, 22 March 2016. TDK’s range of EPCOS EMC power electronics filters is available in Europe at the TTI Inc. distributor of electronic components based on Fort Worth, Texas.

This EPCOS EMC filter range covers 2-line, 3-line and 4-line filters as well as feed-through filters and capacitors, output filters and output reactors. The filters are suitable for all kinds of power supplies, frequency converters for drives, and traction and converters for solar and wind power systems.

TDK’s IEC inlet filters are available in three models: without fuse for 1 amp to 20 amps current, with fuse for 1 amp to 10 amps current and with fuse plus switch for 1 amp to 10 amps current. An optional medical version is available in each type with low leakage current. The devices are all approved to UL/CSA, plus ENEC approval either granted or pending.

TDK’s 2-line SIFI filters are a modular system based on five product lines, covering a wide insertion loss range and different terminal styles. Current rating ranges from 2 amps to 36 amps. As well as standard devices, there are medical versions with low leakage current. TDK’s 2 line SIFI filters are UL/cUL/ENEC approved.

TDK’s 2-line B84142A*166 series filters for frequency converters are 10-amp to 30-amps at 250 volts AC devices for drives to 4 kilowatts. They are compact, high performance EMC filters with low leakage current, dedicated for applications with 30 milliamp RCD use.

Related: 1000-Watt power supplies for ground-based satellite equipment introduced by TDK Lambda

New 3-line and 4-line EMC filters are available in different families for converters and power electronics. All feature compact design and high performance, including the B84143A**166 (10-amp, 20-amp, 35-amp at 520 volts) 3-line filter up to 35 amps for drive applications.

They feature low leakage current and are optimized for short motor cable lengths of up to 10 meters for class C1 and 25 meters for class C2. Another new standard range of EMC 3-line filters for drive applications is the B84243A* series from 3 amps to 280 amps.

TDK’s EPCOS EMC filters offer a number of output solutions, including different output solutions for drives, dv/dt choke and dv/dt filters, since-wave filters and TDK’s proprietary SineFormer EMC sine-wave filter, which removes the need for shielded cables.

For more information contact TTI online at www.ttieurope.com.
