75-Watt DC-DC converter power electronics for industrial applications introduced by TDK Lambda

SAN DIEGO, 3 May 2016. TDK-Lambda Americas Inc. in San Diego is introducing the 75-Watt TDK-Lambda i6AN series of negative output non-isolated DC-DC converter power electronics devices for industrial, communications, test and measurement, and medical applications.

May 3rd, 2016
By Mil & Aero staff
By Mil & Aero staff

SAN DIEGO, 3 May 2016. TDK-Lambda Americas Inc. in San Diego is introducing the 75-Watt TDK-Lambda i6AN series of negative output non-isolated DC-DC converterpower electronics devices for industrial, communications, test and measurement, and medical applications.

The devices can operate from an input voltage of 9 to 40 volts to deliver an output voltage adjustable from -3.3 volts to -30 volts and output currents to 8 amps.

In a 1/16th brick form factor, measuring 33 by 22.9 by 12.7 millimeters, the converters can be used with a single-output AC-DC power supply of 12, 24, or 36 volts to generate additional regulated high-current outputs, with or without battery backup.

The devices have efficiencies to 94 percent, and minimize power losses to operate in harsh ambient temperatures of -40 to 125 degrees Celsius even with low airflow. An optimized dynamic voltage response reduces the need for external output capacitance to help reduce board space requirements.

Related: 1000-Watt power supplies for ground-based satellite equipment introduced by TDK Lambda

The models include an output voltage adjustment pin, positive or negative logic remote on-off, remote sense, input under-voltage, over-current and thermal protection. All models are certified to UL/CSA 60950-1, IEC/EN 60950-1 and carry the CE mark for the Low Voltage and RoHS2 Directives.

For more information contact TDK Lambda online at www.us.tdk-lambda.com.
