Navy asks Northrop Grumman to build AN/WSN-7 ring laser gyro shipboard navigation in $210.1 million deal

Oct. 8, 2020
The AN/WSN-7 ship inertial navigation system senses ship motion and computes position, velocity, attitude, and heading in digital and analog formats.

WASHINGTON – U.S. Navy shipboard navigation and guidance specialists are continuing their efforts to squeeze all the life they can out of the AN/WSN-7 ring laser gyro navigation system for Navy surface vessels and submarines.

Officials of the Naval Sea Systems Command in Washington announced aconteract with a $210.1 million ceiling last week to the Northrop Grumman Corp. operating unit in Charlottesville, Va., to build more of the company's AN/WSN-7 navigation systems.

The AN/WSN-7 is a self-contained, ring laser gyro inertial navigation system that senses ship motions, computes the ship's precise position, velocity, attitude, heading, and rates in digital and analog formats, and forwards the data to other vital ship systems.

The WSN-7 has been in service with the Navy for decades, and was designed as a replacement for spinning-mass gyro navigation equipment aboard Navy warships. The system is as a more reliable ring laser gyro-based replacement for the old WSN-2 navigation system.

Related: Honeywell to replace ring laser gyros to keep Navy AN/WSN-7 shipboard navigation functioning

Navy officials are extending the life of the WSN-7 as long as possible as they develop a WSN-7 replacement.

Northrop Grumman is developing the Inertial Navigation Systems Replacement (INS-R) Inertial Sensor Module (ISM) as a replacement for the WSN-7, to enable surface vessels to navigate accurately without GPS satellite navigation.

Northrop Grumman reported completion of the ISM's preliminary design review in May 2016, and critical design review in June 2018. The ISM will be a critical component of the WSN-12 replacement.

Related: Northrop Grumman keeps Navy shipboard navigation running while looking for new technologies

The INS-R will provide mission critical ship positioning, velocity, and altitude data to shipboard sensors, combat systems, guns, and missile systems. It will use an open-systems architecture using a modular design, standards-based interfaces, and widely supported consensus-based standards.

The AN/WSN-7, meanwhile, uses 25-year-old technology based on the NATO MK49 inertial navigation system deployed in the late 1980s. The INS-R will provide improved real-time navigation for Navy surface warships, and enable future technology growth.

The standard WSN-7 shipboard configuration consists of two independent cabinets for redundancy and survivability. It is not be susceptible to jamming or detection by enemy forces.

Related: Northrop Grumman to develop new Navy shipboard navigation system to replace ageing AN/WSN-7

The ring laser gyro uses two counter-propagating laser beams operating on different frequencies with the difference dependent on rotation rate. Measurement of this difference provides the rotation angle or rotation rate about the device's sensitive axis.

Compared with older spinning-mass gyro navigation systems, ring laser gyros are much smaller, do not resist changes in direction, are frictionless, have low power consumption, and feature almost no moving parts to enhance reliability while still providing adequate accuracy.

On this order Northrop Grumman will do the work in Charlottesville, Va., and the contract is for three years.. For more information contact Northrop Grumman online at, or Naval Sea Systems Command at
