DARPA needs rugged ultra-small clocks to maintain positioning, navigation, and timing (PNT) without GPS

May 23, 2022
H6 project to develop ultra-small, low power clocks that can maintain microsecond precision for a week in temperatures from -40 to 85 degrees Celsius.

ARLINGTON, Va. – U.S. military researchers are asking industry to develop ultra-small low-power clocks to help military forces maintain precise positioning, navigation, and timing (PNT) in case that GPS navigation satellites are damaged, destroyed, or jammed.

Officials of the U.S. Defense Advanced Research Projects Agency (DARPA) in Arlington, Va., issued a broad agency announcement on Tuesday (HR001122S0038) for the H6 program.

The H6 project of the DARPA Microsystems Technology Office seeks to develop ultra-small, low power clocks that can maintain microsecond precision for at least one week in temperatures from -40 to 85 degrees Celsius.

H6 refers to an 18th Century British ocean-navigation project that in five increments developed precise chronometers the helped British ocean navigators determine their vessels' positions in longitude to prevent catastrophes like the 1707 Scilly Naval Disaster that wrecked four British warships and killed between 1,400 and 2,000 sailors due to navigational errors.

Related: DARPA seeks to wean smart weapons off GPS with hybrid inertial navigation system-on-a-chip

British inventor John Harrison developed five generations of clocks, which he called H1 through H5; the last one was the first marine chronometer with the accuracy necessary to determine longitude accurately. Navigators can determine latitude with sextants using the sun and stars; determining longitude, however, requires precise clocks.

H6 is the spiritual successor to Harrison’s maritime chronometers. While the longitude problem was the preeminent PNT challenge of the last millennium, GPS denial is the greatest problem today, DARPA researchers point out.

Ubiquitous compact timing today remains critical not only for navigation, but also for communications, electronic warfare (EW), and intelligence, surveillance, and reconnaissance (ISR).

A tactical-grade clock that maintains weeklong microsecond timing would remove PNT timing from dependence on navigational satellites for the majority of U.S. military missions, and enable signal assurance, pervasive communications security, and high-bandwidth communications.

Related: AOSense to develop navigation chip that combines solid-state and atomic inertial sensors

Today, no such fieldable tactical-grade clock exists; while there are clocks which can achieve the necessary performance, their size, weight, and power consumption (SWaP) limitations preclude their use in a tactical setting.

DARPA researchers are interested in SWaP-constrained clocks that rely on compound mechanical clock technologies; sub-terahertz molecular clock technologies; or something completely different.

H6 will be a five-year, three-phase program. The first phase will focus on clock dependence on temperature and SWaP reduction, while the second phase will focus on clock aging throughout the tactical temperature environment. The third phase will demonstrate an integrated tactical-grade clock and build five clocks.

Companies interested should upload abstracts by 16 June 2022, and full proposals by 8 Aug. 2022 to the DARPA BAA website at https://baa.darpa.mil. Email questions to [email protected]. More information is online at https://sam.gov/opp/fba0b64702914a0ab95f26681362cf79/view.
