Space Force asks industry to develop radiation-hardened non-volatile memory for next-generation space uses

Jan. 16, 2023
ANGSTRM seeks to develop rad-hard non-volatile memory that combines packaging and radiation-hardening with state-of-the-art commercial technology.

KIRTLAND AIR FORCE BASE, N.M. – Spacecraft experts in the U.S. Space Force are reaching out to industry to find companies able to design next-generation radiation-hardened non-volatile memory chips for future military applications in space.

Officials of the U.S. Air Force Research Laboratory's Space Vehicles Directorate at Kirtland Air Force Base, N.M., issued a solicitation on Thursday (FA9453-21-S-0001) for the Advanced Next Generation Strategic Radiation hardened Memory (ANGSTRM) project.

ANGSTRM seeks to develop a strategic rad-hard non-volatile memory device with near-commercial state-of-the-art performance by using advanced packaging and radiation-hardening techniques with state-of-the-art commercial technology.

Advancing strategic rad-hard non-volatile memory technologies is critical to support strategic missiles, missile defense, and military space systems, researchers say. Non-volatile memory devices retain their data even when they lose power.

Related: Radiation-hardened space electronics enter the multi-core era

The U.S. military uses strategic rad-hard non-volatile memory across many space programs and strategic systems that must withstand the effects of naturally occurring radiation in space, as well as radiation from nuclear explosions.

Ideally, the DoD would have access to non-volatile memories with the performance and density of commercial state-of-the-art devices; unfortunately today's commercial technologies are not able to withstand the radiation and thermal environments where the military deploys systems. Many military systems, moreover, must use trusted on-shore electronics manufacturing.

Today's rad-hard non-volatile memory technologies are limited in performance and density, so system designers require several devices to meet on-board storage requirements, which drives the size, weight, power, and cost (SwAP-C) of system storage.

The U.S. Space Force researchers are interested in combining radiation hardening to state-of-the-art CMOS and memory technologies to scale density beyond the levels of a single chip, and create qualified strategic rad-hard non-volatile memory for use across military space and strategic systems.

Related: Radiation hardening meets smart satellites

A multi-phased development approach is necessary to assess the scalability of these technologies while still meeting the radiation requirements for the space and strategic environments.

Researchers want to industry to develop rad-hard memories with monolithic memory densities of 4 to 16 gigabits, and with multichip module densities of 32 to 128 gigabits that will last without refresh for 10 to 15 years.

Memory devices should operate with no more than 10 milliwatts of power, with 1 milliwatt performance preferred. Total standby power requirements are no more than 10 milliwatts, and as little as 10 milliwatts. These devices should operate in temperatures from -40 to 125 degrees Celsius, and eventually down to temperatures of -55 C.

Resistance to total-ionizing-dose radiation should be as low as 300 kilorads, and as high as 1,000 kilorads, with fewer than 10 to 12 single-event upset errors per bit day. Single-event latchup resistance should be more than 72 MeV-Cm2/mg, with single-event gate and dielectric rupture of 72 to 100 MeV-Cm2/mg.

Related: Space industry eyes radiation-tolerant high-voltage transistors to enhance spacecraft power efficiency

Ultimately, the ANGSTRM project seeks to develop a full-scale prototype device, provide device characterization and radiation test reports, and provide a qualification plan with a path to achieve a QML-standard product.

Companies bidding should demonstrate the capability for marketing and product support, and submissions must address the design, layout, and fabrication of the full-scale device in a trusted on-shore facility. Bidders also must provide space-qualification plans, discuss their strategic rad-hard design approach, and identify long-term sourcing strategies for intellectual property.

Companies interested should submit white papers no later than 13 Feb. 2023. Bidders must prepare white papers using the template available online at https://valideval.com/star_documents/, saved as a PDF, and submitted via DoD Safe at https://safe.apps.mil.

Related: Radiation-hardened serial interface ferroelectric RAM (F-RAM) for space applications introduced by Infineon

To submit white papers, email the Space Force's Brenda Hamilton at [email protected], or Jeffery Martinez at [email protected] no later than 8 Feb. 2023 to receive a DoD Safe drop-off request. Companies that submit promising white papers will be invited to submit full proposals.

Email questions or concerns to the Space Force's Francis Eggert at [email protected], or Jeffery Martinez at [email protected].

More information is online at https://sam.gov/opp/34f03218e37a451f91ab2a34dfada6bb/view.
